| Specifications of Retevis RB629 | ||
| GENERAL | Frequency Range | PMR446 |
| Rated Voltage | 3.7V DC | |
| Memory Channel | 16 | |
| Battery | 1100mAh | |
| Frequency Sensitivity | ±0.5ppm | |
| Antenna Impedance | 50Ω | |
| Operation Temperature Range | -30℃~+60℃ | |
| TRANSMITTER | RF power | 0.5W |
| Modulation type | 16kΦF3E | |
| Modulation distortion | <5% | |
| Adjacent channel power | ≥65dB | |
| Audio response | +6.5 ~ -14dB | |
| Max FR.Deviation | ≤±5KHz | |
| Spurious Radiation | ≤7.5μW | |
| Current | ≤1200mA | |
| Modulation Noise | <-40dB | |
| Intermediation sensitivity | 8-12mv | |
| RECEIVER | Receiving sensitivity | 0.2μV |
| Adjacent channel selectivity | 65dB | |
| Occupied Bandwidth | ≤16KHz | |
| Current | Standby 55mA, working 150mA | |
| Reference Frequency | 26.000MHz | |
| Inter-modulation | ≥60dB | |
| Spurious | ≥55dB | |
| Audio response | +7~-12.5dB | |
| Audio distortion | <5% | |
| Audio power | 500mW | |
|
Specifications of Six-Unit Multi-Charger |
|
|
Output Voltage of Each Unit |
DC 4.2V |
|
Output Current of Each Unit |
500mA |
|
USB Port |
5V/1A |
|
Size |
250*200*60mm |
|
Weight |
1.2kg |
|
AC and DC Adapter Cable Length |
150cm/59.06in |
● All Channel Pair Function
● One Channel Pair Function
● VOX Hands-Free
● Emergency Alarm
● Squelch Function
● Monitor Function
● Scan Function
● Busy Channel Lockout (BCLO)
● Time-out-Timer (TOT)
