Frequency range |
UHF(450-470MHz) |
Channel number |
30/16 |
Audio distortion |
<5% |
Operating temperature |
-20℃+50℃ |
Antenna impedance |
50Ω |
Transmit power |
≤5W |
Frequency stabilization |
±2.5ppm |
Maximum Deviation |
Wideband: ≤5kHz; Narrowband: ≤2.5kHz |
Stray radiation |
TX≤0.25uW@-36dBm; RX≤2nW@-57dBm |
Modulation mode |
Wideband:16KφF3E;Narrowband:11 KφF3E |
Emission current |
≤1500mA |
Receiver Sensitivity |
Wideband: ≤0. 25uV@-119dBm; Narrowband: ≤0. 282uV@-118dBm |
Adjacent Channel Selectivity |
≥65dB |
Spurious response rejection |
≥55dB |
Intermodulation |
≥60dB |
Working voltage |
DC 7.4V |
