RT51 PoC Handset Radio
Bulk order Inquiry
Personalize your device
OverView
1. Pls read below information carefully before you order
-
First, about the quantity, Pls try to order more than 2pcs RT51 radios,not only one. or else, you couldn't use RT51 radios.
-
Second, You have to order One Cable ( click C9018A or C9055A ) together with your order
-
Third, after you got RT51 POC radios, pls buy and insert your own SIM card, either T-Mobile or AT&T carrier in the US. For a regular use, 500 MB data plan will be enough.
-
Finally, You have to order 10$ Yearly Subscription fees Per radio, Per year. ( Pls Click BC01to order together). it depends on the quantity of your RT51 PoC radios . (e.g. Now you have 10pcs RT51 PoC radios in total. besides, you have to order 10pcs BC01together at least per year.)
2. Why RETEVIS RT51 PoC Handset Radio?
Pls Read the article here : about the benifits of RETEVIS RT51 PoC Handset Radio
Or the basic knowledge here: about the knownledge of RT51 PoC Handset Radio
Feature:
-
PTT One-Touch Talk,Easy to use.
-
Unlimited Range Coverage
-
Battery power voice prompt
-
Low battery alert
-
Talk Priority Settings
-
Loud Crystal Clear Voice
-
Software remote update
-
List quick search
-
PTT Kibitz in a group
-
Talk Permit Tone
-
9 quick call keys
-
GPS feature
3. How to use your RETEVIS RT51 PoC Handset Radio? Click to read more below:
Standard Accessories:
-
1 x RT51 PoC Radio
-
1 x Antenna
-
1 x Battery
-
1 x Adapter
-
1 x Charger
-
1 x Belt Clip
-
1 x Hand Strap
-
1 x User Manual
What’s in the Box?
-
1 x RT51 PoC Radio
-
1 x Antenna
-
1 x Battery
-
1 x Adapter
-
1 x Charger
-
1 x Belt Clip
-
1 x Hand Strap
-
1 x User Manual
Standard Accessories:
Spec
Technical parameters:
Technical indicator |
Working voltage |
3.7V |
Operation system |
Linux system |
|
Language |
Chinese/English |
|
LTE FDD frequency |
B2 |
Tx frequency:1850~1910MHz Rx frequency:1930~1990MHz |
B4 |
Tx frequency:1710~1755MHz Rx frequency:2110~2155MHz |
|
B5 |
Tx frequency:824~849MHz Rx frequency:869~894MHz |
|
B12 |
Tx frequency:698~716MHz Rx frequency:728~746MHz |
|
B17 |
Tx frequency:704~716MHz Rx frequency:734~746MHz |
|
WCDMA |
B24 |
Tx frequency:1850~1910MHz Rx frequency:1930~1990MHz |
B5 |
Tx frequency:824~849MHz Rx frequency:869~894MHz |
|
General |
Antenna |
External main antenna/GPS antenna built-in |
Screen |
1.77 SPI Color Screen,Resolution:128*160 |
|
CPU |
ZET ME3630 U1C |
|
Batterycapacity |
≥4000mA |
|
Rx sensibility |
-106dBm |
|
Max.Tx power |
23dBm~25dBm@All up bits |
|
Workingtemperature |
-30℃~+75℃ |
|
Storage temperature |
-30℃~+75℃ |
|
Audio output power |
2W@10% distortion |
|
Performance |
Receiver Type |
56-channel u-blox 7 engine GPS/QZSS L1 C/A, GLONASS L1 FDMA SBAS:WAAS, EGNOS, MSAS |
Maximum |
Up to 10Hz |
|
Update rate |
Accurancy |
GPS GLONASS |
Positioning |
2.5m CEP 4.0m |
|
SBAS |
2.5m CEP N.A. |
|
Capture |
Cold start |
20S 30S |
Weight |
5SN.A. |
|
Accurancy |
1S 1S |
|
Sensitivity |
Track |
-161dBm -158dBm |
Cold start |
-148dBm -140dBm |
|
Warm start |
-148dBm -145dBm |
|
Assisted GPS |
AssistNow OnlineAssistNow Offline |
|
Oscilator |
Built-in(MAX-7Q/7W), the ordinary crystal(MAX-7C) |
|
RTC crystal |
Built-in(MAX-7Q/7W) or more cost-effective solution |
|
An-ti interference |
Active CW detection and removal |
|
Storage |
ROM |
|
Support |
Active antenna and passive antenna |
|
Voltage Level |
Power consumption |
16.5mA@3V(Continuous Mode) |
Power Supply |
1.4V-3.6V |
