Feature：
-
CTCSS&DCS
-
Squelch Function
-
TOT(Time-out Timer)
-
VOX Function
-
Battery Save Function
-
Low Battery Prompt
-
Key lock
-
Frequency Hopping
-
Voice Companding
-
Main Mode
|
General |
|
|
Model Number |
RT619 |
|
Frequency Range |
EU:PMR446 |
|
Channel Capacity |
16 |
|
Battery Capacity |
Li-ion 1300mAh |
|
Working Voltage |
DC 3.7V |
|
Antenna Impendence |
50Ω |
|
Working temperature |
-20-60℃ |
|
Weight (Include battery) |
90g |
|
Size(Include antenna) |
122x50x18mm |
|
Transmitter |
|
|
Output Power |
≤0.5W |
|
Modulation |
16K F3E / 11K F3E |
|
Maximum Frequency Deviation |
1≤5KHZ / ≤2.5KHz |
|
Remanent Radiation Mode |
≤7uW |
|
Electric Current |
≤1.2A |
|
Modulation Distortion |
≤5% (300-3000Hz) |
|
Receiver |
|
|
RF Sensitivity |
≤0.25uV / ≤0.3uV |
|
Audio Frequency Power |
≥200mW |
|
Audio Distortion |
≤5% |
|
Inter-Modulation |
≥60dB |
|
Adjacent Channel Selectivity |
≥65dB |
|
Spurious Rejection |
≥55dB |
- Portable
- Ultrathin fuselage
- License free
