- Built-in GPS, DSC and MOB Function
- IP67 Waterproof and Floating
- Double/ Tri-Watch
- Standard NMEA Interface
Description
| Frequency Range | TX：156.025-157.425MHz |
| RX：156.050-163.275MHz | |
| Type of Emission | FM(16K0G3E)/DSC(16K0G2B) |
| Frequency Stability | ±10ppm |
| Battery Pack | DC7.4V,1500mAh |
| Operating temperature | -15℃ ~ + 55℃ |
| Dimension (HxWxD) | 61*141*43mm |
| Weight | 315g（with battery, antenna, and belt clip) |
| Waterproof Level | IPX7 |
| Receiver | |
| Receiving sensitivity | ≤0.22μV |
| Squelch Sensitivity | ≤0.22μV |
| HUM and Noise | ≥40dB |
| Adjacent Channel Selectivity | ≥70dB |
| Spurious Response Rejection Ratio | ≥70dB |
| Intermodulation Rejection Ratio | ≥68dB |
| Audio Output Power | ≥0.5W(10%) |
| Transmitter | |
| RF power | 5W/1W |
| Maximum Frequency Deviation | ±5kHz |
| Spurious Emission | ≤0.25μW |
| Adjacent channel power | ≥70dB |
| Audio Harmonic Distortion | ≤10% |
| Current Drain | ≤1.5A(High Power) |
| ≤0.7A(Low Power) | |
| ≤0.2A(Maximum Audio Output) | |
| GPS Receiver Apply to long-term tracking, (When signal strength ≥-130dBm, 5 satellites visible) | |
| TIFF Cold Boot | ＜1 minute |
| TIFF Warm Boot | ＜10 seconds |
| Horizontal position Precision | ＜ 10 meters |
Package
RelevantDocuments
Total Folders:
1
Total Files:
1
Manual (1 files)
RM40-User-Manual
