RT10 Two-Way Radio for Business 128-Channel 900 MHz
- Retevis RT10 is a digital two way radio that works on 900MHz frequency.
- Digital and Analog mode can connect to more people.
- High sound quality gives users a good experience.
- The programming cable is C9018A
- NOTE: Programming software: please click "support" to download
Order Handling Time within 3 Working days(Pre-sale products excluded).
Bulk order Inquiry
Personalize your device
OverView
Retevis RT10 902-928MHz radio.Designed for business operations, the RT10 radio will free your time from regulatory paperwork and licensing applications and saving radio licensing fees.
Digital and analog compatible,Support digital and analog two communication modes to ensure that the original analog products smooth transition to digital products to meet different communication needs
High sound quality, This digital two-way radio uses advanced AMBE +2TM voice processing technology to achieve higher quality
Prominent functional keys, Programmable button can be used to quickly access call features like Call All/Page All, to talk to radios without searching through your channel list.
What’s in the Box?
- 1 x RT10 Tow Way Radio
- 1 x Antenna
- 1 x Battery
- 1 x Adaptor
- 1 x Belt Clip
- 1 x Sling
- 1 x User Manual
- 1 x USB Charger
Spec
Main technological specification
Frequency range | 902 - 928 MHz |
Channel Capacity | 50CH(up to 128) |
Channel Spacing | 12.5KHz |
Operating Temperature | -25℃~+60℃ |
Operating Voltage | DC7.4V |
Antenna Impedance | 50Ω |
Microphone Impedance | 2.2KΩ |
Battery | 1400mAh |
Dimension | 220×60×35mm(including antenna) |
Weight | 278g |
Transmission
Output power | 1W |
FM modulation | 8K¢F3E |
4FSK digital modulation | 7K60FXE |
Vocoder type | AMBE++or SELP |
Digital Protocol | ETSI-TS102 361-1,-2, |
Harmonic | ≥70dB |
Signal-to-noise | ≤-40 dB |
Rated audio Distortion | ≥5% |
Frequency Stability | ±2.5ppm |
Max Frequency Stability | ≤-40dB |
Reception
Sensitivity (12dB SINAD) | ≤-119dB |
Digital 0.3μV/BER5% | |
Signal-to-noise Radio | ≥40dB |
Adjacent channel selectivity | ≥60dB |
Intermediation (Wide/ narrow) | ≥55dB |
Spurious Response Rejection | ≥65 dB |
Audio power | 1W |
Audio distortion | <5% |
Frequency Stability | ±2.5ppm |
Battery life under 5-5-90duty | 14.8 hours |
Feature
Retevis RT10 902-928MHz walkie talkie is Designed for business operations, the RT10 radio will free your time from regulatory paperwork and licensing applications and saving radio licensing fees.
Digital and analog compatible,Support digital and analog two communication modes to ensure that the original analog products smooth transition to digital products to meet different communication needs
Digital signaling function, Rich calling modes that support protocol, including single call, group call and all call; supports remote inhibit function and other applications
High sound quality, This digital two-way radio uses advanced AMBE +2TM voice processing technology to achieve higher quality
Prominent functional keys, Programmable button can be used to quickly access call features like Call All/Page All, to talk to radios without searching through your channel list.
Supports the use of repeater
- 50-channel(up to 128)
- Single call, group call and all call
- Double time slot, color code (0-15)
- Region selection
- Power saving,low voltage alarm
- Scan
- Monitoring, SOL ( 1-10level)
- Tail cancellation
- Side key definition
- VOX, TOT (495S)
- Encryption function
- Relay / de-netting function
