OverView
Spec
| Transmitter | |
|---|---|
| Output Power | 1W / 5W |
| Transmit Spurious Emissions | ≤ -20dBm |
| Adjacent Channel Power Ratio | ≥ 70dB (wideband), ≥ 60dB (narrowband) |
| Transmit Audio Distortion | ≤ 5% |
| Input Impedance | 2KΩ (microphone) |
| Bandwidth | 25kHz / 12.5kHz |
| Signal-to-Noise Ratio (SNR) | N: ≥ 35dB, W: ≥ 40dB |
| Current Consumption | ≤ 1.8A (high power), ≤ 1A (low power) |
| Receiver | |
|---|---|
| Receiver Sensitivity | ≤ 0.22µV / -120dBm |
| Adjacent Channel Selectivity | W: 65dB, N: 60dB |
| Maximum Receive Current | ≤ 450mA |
| Output Impedance | 16Ω (speaker) |
| Squelch Sensitivity | ≤ -122dBm |
| Audio Output Power | ≥ 1W (10%) |
| Receiver Signal-to-Noise Ratio | N: ≥ 35dB, W: ≥ 40dB |
