OverView
two way vhf radio Solid quality, well-made, two-color injection molding process
Companding technology to make the call clearer
License-free use, MURS spreads more widely in open areas
Large capacity and long standby time (4400mAh)
Spec
| General Specifications | |
| Frequency Range | MURS |
| Channel Capacity | 5 CH |
| Channel Spacing | 12.5KHz |
| Antenna Impedence | 50Ω |
| MIC Impedence | 2.2kΩ |
| Working Voltage | 3.7V DC |
| Operating temperature | -30~+60°C |
| Frequency Stability | ±2.5×10-6 |
| net weight | 260g |
| Transmitter | |
| Carrier Frequency Tolerance | ±2.5×10-6 |
| Output Power | ≤2W |
| Modulation Sensitivity | 11±2mV |
| Modulation Distortion | ≤5% |
| Modulation Limit | ≤5 kHz |
| Occupied Bandwidth | ≤16 kHz |
| Modulation Characteristic | ±3dB |
| Spurious Radiation | ≤7.5μW |
| Adjacent Channel Selectivity | ≤-65 dB |
| Transmitting SNR | ≥40 dB |
| Receiver | |
| Reference Sensitivity | -121dBm |
| Squelch Sensitivity | ≤0.22μV |
| Audio Power | 1W |
| Audio Distortion | ≤5% |
| Modulation RX Bandwidth | ≥∣±7kHz∣ |
| Audio Response | ≥+2dB, ≤-10dB |
| Co-channel Injection | ≥-8 dB |
| Block | ≥85 dB |
| Channel Selectivity | ≥65 dB |
| Receiving SNR | ≥45 dB |
Feature
- Brand: Retevis
- Model: RB17V
- Large capacity and long standby time (4400mAh)
- Solid quality, well-made, two-color injection molding process
- Companding technology to make the call clearer
- 9 levels of squelch, to achieve an ideal call
- License-free use, MURS spreads more widely in open areas
- There is no interference from ordinary walkie-talkies, which is very suitable for commercial applications (or users who need more privacy)
- One-key remote alarm, one-key open VOX
- Indicator
- Channel Switch
- Power Switch
- PTT
- Monitor
- Squelch Level
- TOT
- Voice Annunciation
- Power Saving Function
- Battery Voltage Alert
- Busy Channel Lockout
- High /Low Power Switch
- VOX
- OT/DQT
- Remote Alarm Function
- Compandor
Product Reviews
Support
Firmware/Software
Firmware/Software
- RB17V-software
Unzip: Windows 64bits：https://www.7-zip.org/a/7z2201-x64.exe
- win11-DriverInstaller
The win11 driver is compatible with win10, win8 and win7 systems.
